224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯电站用热车机气油生活性好: 高级的气油操作机操控体系，独具的STC、ESTC 等级操作机操控体系，特出设计制作的汽缸最上层燃燒室，直流高压喷洒于气油，积极主动吸雾，燃燒积极主动。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯生产发电用发起机瞬态安全性能不错: 好的发起机局部设计的概念，加上康明斯特殊的EFC系统化，管控要求高，初始化失败时期快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯并网发电用打着机升效率高: 整个设计的省油的suv.内部结构安排恰当，运转能保持稳定。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷型号规格 QSNT. QSK19. QSK38. QSK50充分满足中国国家非路面再者过程及北美地区Tier2. Tier 3排污法律规定规定要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备件管理必须性好， 汽车发因素启动及定期维护调养便于，的成本高。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

功效範圍 Power Range   224-310KW结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L内部结构尺码 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净线质量 Dry Weight   940kg

224-310KW康明斯发电机组用打火机的特殊性：球体积较小， 再压缩比低， 除雾器新鲜空气微波加热，非常易启动时，手机移动车载影音交流电源的优先。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

汽车发主观因素机型	常见最大功率(kW)Prime Power	备用电源效率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
